The Micro-R-Press and the long way to get there.

 Some month agao, Bill Ritchie asked me about laser-cutting from 3 mm plywood, to make a print-press.

He sent me the illustrator files of his "Mini-Rembrandt-Press" (old name = "WeeWoody Rembrandt-Press"). I translated some messures from inch into cm, add a handweel and start cutting. It needs some hours, but afeter this, I starded with the assembly, but failed partially. The result, I called "Qusimodo-Press", cause it became crooked, but ist works, 'cause the rollers are still parallel...

Now it is so, that the print format is "ATC"-size. The size of (Artists) Trading Cards.

But the smallest size, I'm working with is 4 x cm.

So I've had an idea:

Press shink to 55% of the Original.


Ok, this is only an model, to find out the right design, but it is for 4 x 4 cm-prints on 5 x5 cm paper!

So I took on the challenge of constructing all parts, also the rollers of the press, from 3 mm plywood.

Laser cutten plywood and the drawing of that plate.


Next step was to realise a working-model of the Micro"R"Press, as I called it.

And it works, I could assambly the prototype of a Micro"R"Press.

The Micro"R"Press with its gear(s).

I prefer a gear drive version, like the first "WeeWoody Rewmbradt Press". This means fixed rollers, but better power transmission.

And so I started to test differend printing-plates:

Different plates, I used.

Then I've had the idea to print a booklet in 5 x 5 cm. That need printing-plates fora paper size of 5 x 10 cm, or bigger. So I made a "long-printing-bed":

Long-printing-bed wit print and cliche.



The finished booklet, 5 x 5 cm.

But then, the press blocked... the handweel didn't go forward, or back...SHOCK.

Early end of a great idea?

I thought about an find a way to catch the big pressure, by adding "side-supports" for the rollers:

New version of the press with "roller-supports" at the sides.

And now, the Micro"R"Press is perfect for printing:

With the "universal-long-bed" it is possible to print 5 x10 with no problems. So stamps, for exsample. The print-plate, and later, the perforation is made with the same lasercutter, I've used to cut the parts of the press.

In the meantime, I've also made a manual for assambly the parts of the press:

Three pages of the manual in german / english.

 The first "DIY-Kit", just out of the laser has arrieved in Seattle now.

The press is no chidren's toy, but a nice tool, on the desk for making just a print, if you have an idea.

Best materials for the print-plates are photopolymere (clear-stamps), or soft-cut-plates. But with some practice, it is possible to print etchings (intaglio).

Vision and Realisation.





Saturday 8 May 2021

Thermofaxprint „quick&dirty“ with floating Motives & Material-Print

The Thermofaxprint "quick&dirty" with floating Motives. Size = A6


You know, that artworks often arises during their development process.
In prints, the motive usually is given.
Another point is, using thin things (leafs, feathers,…) in the lay-out of a (screen-, intaglio-)print.

The cheap thermo-copier with 200 dpi solution.

This time I did both: move/exchange the elements after every printing pass and use leafs and and parts of feathers.
For this I used the simple „China-Tattoo-Copier“ and the thermofax-master vom „Gestetner“ (now available from „Ricoh“).
Additional I covered the carrier (240 g/qm paper) with a thin, clear plastic film.
Between carrier and plastic film, I put the items.

The thermofax-master I printed as usually (see here).
For this trial I used the CMYK-colors, show the different levels more simple.
The pur printing-time is very short: for the 4 colors I need less then 2 hours (12 copies).
Between the 2nd. color, the prints needed 2 hours to dry, after the 3rd color I let them dry overnight.

For a quick result, I use the size of a postcard.
The „China-Tattoo-Copier“ is limited to the size of A4, but you can use this size (or a smaller one) as pattern for printing on bigger formats, or fabric (for example with T-Shirt-Colors). Similar to the traditional thermofax-print,.

The carrier with the covering plastic film.

The items for the yellow-print. Black paper, feathers.


Yellow printing with thermofax-master from "Gestetner" / "Ricoh"

The items for the magenta-print. Paper + leaf.

The items for the cyan-print. Paper + parts of feathers.

The leaf for the black-print.


Printed card in the stand.
Have a good print and stay healthy
-ekk-

Thursday 4 February 2021

#WBZ, the next 4 Cards

Phuu, es ist wie mit dem Virus: alles dauert länger, als gehofft, und dazwischen machen wir "viele Erfahrungen".
Doch wie dem auch sei, die nächsten 4 Karten sind gedruckt, die Belegexemplare verteilt, an F., Brigitte + Hans-Jürgen, an Lorenz und an Paul.

Fangen wir mit der Karte von F. an. Kein leichtes Unterfangen, doch das Wort "Corona" auf ihrem Stundenplan gab mir den "roten Faden vor.

Phuu, it's like the virus: everything is taking longer than we had hoped, and in between
we have "a lot of experiences".
Be that as it may, the next 4 cards have been printed, the specimen copies distributed,
to F., Brigitte + Hans-Jürgen, Lorenz and Paul.

Let's start with the picture from F. Not an easy undertaking, but the word "Corona"
on your timetable gave me the "central theme".

Die Vorlage.

Ich entschloss mich, den Ausschnitt im Thermofax-Druck, mit einem Hot-Embossing-Effekt zu drucken.

I decided to use thermofax printing to print the cutout with a hot embossing effect.

Der Scan vom fertigen Druck.

Etwas verwinkelt abfotografiert, um den Glitzer mehr zur Geltung zu bringen.

 Die Karte für Brigitte und Hans-Jürgen war ein echter "Challange". Um Beiden gerecht zu werden, habe ich die Themen Fotografie und Briefmarken miteinander verbunden. Das Lay-out der Fotos und Texte gehört zur Arbeit von beiden, eine Vorarbeit zu Brigittes neuem Buch.

The card for Brigitte and Hans-Jürgen was a real "challenge". In order to do both justice,
I combined the subjects of photography and postage stamps. The layout of the photos and
texts is part of the work of both, a preliminary work
Brigittes new Buch.

Die Vorlage von Brigitte + Hans-Jürgen zur #WBZ-Postkarte.

Das Ergebnis: Thermofaxdruck und Lasergravur (die Perforation).

Die Rückseite der Karte mit einer Gummierung (Siebdruck)






Es ist immer wieder spannend verschiedenste Techniken und Geräte für die Erstellung eines Produktes zu nutzen. Oder auch: mal wieder "viel Erfahrungen gemacht" ;-)It is always exciting to use a wide variety of techniques and devices to create a product.
Or also: once again "had a lot of experience" ;-)




Wednesday 3 February 2021

# WBZ-Postkarten, 2. Teil

 (wie es scheint ist die Länge der Posts inzwischen begrenzt, darum diesmal in 3 Teilen.)

(It seems the length of the posts is now limited, so this time in 3 parts.)

Die Vorlage von Lorenz



Ich wusste von Anfang an, dass hier Reduktion das Schlüsselwort ist. So erstellte ich eine Laser-Xylogravur als Ausgang, Drucke diese auf feuchtes Tiefdruckpapier als Blind-Prägung mit Gold an einzelnen Stellen. Als Druckmaschine diente wieder einmal die solide Mini-Halfwood-Presse.

I knew from the start that reduction was the key here. So I created a laser xylogravure
as an output, printed it on damp gravure paper as a blind embossing with gold in individual places.
Once again, the solid was used as the printing machine
Mini-Halfwood-Press.

Im Scan ist nicht viel zu sehen, darum folgen noch Fotos mit mehr Schattenwurf.
Not much can be seen in the scan, so photos with more shadows follow.

.

Die mit einem Laser gravierte Druckplatte für Prägung/Druck (Laser-Xylogravur).




The printing plate engraved with a laser for embossing / printing (Laser-Xylogravur).

W.g. der unebenen Oberfläche musste ich die Rückseite im Buchdruck bedrucken (mit der Adana 8 x 5"). Because of the uneven surface, I had to print the back using letterpress (with the Adana 8 x 5").

Die Rückseite der Karte.

Der Bleisatz und die Adress-Linie für die Rückseite. The lead type and the address line for the back.
Leider habe ist der Karton immer noch etwas gewölbt, hoffe dass er sich mit der Zeit und leichtem Druck plan legt ;-)
Unfortunately, the box is still a bit arched, hope that it will lie flat over time and with light pressure ;-)

Tuesday 2 February 2021

#WBZ-Karten, Teil 3

 Last, but not least die Karte von Paul mit "seinen" zwei Dohlen.
Last, but not least, Paul's card with "his" two jackdaws.
Das Original-Foto von Paul.

Um dem "Corona" Rechnung zu tragen, versetzte ich die vordere Dohle in Rotation. Jetzt bildet sie gefährliches "schwarzes Loch", welches virenmässig alles verschluckt. Wie bei den alten Ägyptern bilden nun zwei Dohlen die Wächter des Portals. Deren Status, wird ebenfalls durch einen goldenen Schabel symbolisiert.

In order to take the "Corona" into account, I set the front jackdaw to rotate.
Now it forms a dangerous "black hole", which swallows everything in terms of viruses.
As with the ancient Egyptians, two jackdaws now form the guardians of the portal.
Their status is also symbolized by a golden shield.

Hier der Thermofax-Druck in 3 Farben mit goldenem Hot-Embossing.








Here the Thermofax print in 3 colors with golden hot embossing.
